Talking Any BMW Techs?? Need pinout for DCT shifter

Hoping someone can look this up for me. Attempting to retrofit a DCT/SAT shifter (BMW part number: 61 31 9 208 271; see pic below) into my e46 auto to replace current shifter.




I have Bentley's for my e46 and have the wiring diagram and pin assignments for the current setup. Need pinouts for 12 pin connector on DCT shifter to get lights to work properly. If anyone could post or direct to where I can get it.... greatly appreciated. Delmarco had attempted mod; its his car pictured, but had intermittant light issues.... I will post complete DIY when I get it figured out.
