TrippinBimmer · 01-28-2013, 04:51 PM

Since it warmed up a good bit here in Ms. I start to paint my oil cooler and brackets semi-gloss black to match the rest of the kit.

I started to remove my Oil Cooler for the S/C around to see how I can mount my new engine oil cooler...

Here it is mounted in front of the radiator support and will be behind the sc oil cooler.

Lines routed and fittings are fitted. I will be modifying the AA S/C Oil Cooler Bracket. Similar to the M3 version (AA should just use this bracket for all e46 as it fits and looks much better.)

-Trip
