DIY: Replacing Coupe Edge Protector (drooping door seal)

After trying a variety of glues in vain attempts to permanently fix my failed edge protectors (the felt/rubber door seals), I finally plunked down $386 and bought one of the seals for my coupe. I found a DIY for the sedan, but there are a few quirks and extra steps to pulling it off for the coupe. Hopefully this DIY helps out the coupe owners who want to do this. It took me a little over an hour. Considering it would have taken me that long to get to the dealer, explain the problem and drop off the car, there isn't much of a good reason to pay anyone to do this. If ~I~ can pull it off, anyone can.

First off, I ordered the part from Penske, which has got to be the absolute best parts site on the web. The edge protector showed up a couple days later with a bag of M&Ms (I don't get it either, but they seem to be a very customer-oriented group of folks).
Click image for larger version

Name:	DSCN1858.jpg
Views:	313
Size:	98.1 KB
ID:	363063Click image for larger version

Name:	DSCN1860.jpg
Views:	526
Size:	127.9 KB
ID:	363064
Here's a sideways look at the problem.
Click image for larger version

Name:	DSCN1861.jpg
Views:	685
Size:	123.3 KB
ID:	363065
First step is to disconnect the battery (you'll be working near an air bag). Disconnect the negative terminal first, then the positive. Next step is to pry up the kick plate. It has 8 very sturdy plastic connectors.
Click image for larger version

Name:	DSCN1862.jpg
Views:	595
Size:	159.8 KB
ID:	363066
If any connectors remain in the door, use needle nose pliers to grip them as shown (grab them anywhere else, and they'll break).Click image for larger version

Name:	DSCN1864.jpg
Views:	328
Size:	99.1 KB
ID:	363067
Grab the seal at any spot except near the front fender, and start pulling it away from the car body. You'll find a wire going into your A-pillar and a flap of plastic extending from the edge protector to a small black plug.
Click image for larger version

Name:	DSCN1866.jpg
Views:	597
Size:	164.5 KB
ID:	363069Click image for larger version

Name:	DSCN1867.jpg
Views:	498
Size:	137.0 KB
ID:	363070Click image for larger version

Name:	DSCN1872.jpg
Views:	466
Size:	106.6 KB
ID:	363075
Go wash your hands to avoid getting grime on your interior. Pry off the "HPS" flap on the A-pillar. Use a Torx T-20 to pull out the three Torx bolts under the HPS flap. I had a hell of a time getting these out, but eventually succeeded.
Click image for larger version

Name:	DSCN1868.jpg
Views:	469
Size:	97.2 KB
ID:	363071Click image for larger version

Name:	DSCN1869.jpg
Views:	406
Size:	148.4 KB
ID:	363072Click image for larger version

Name:	DSCN1870.jpg
Views:	413
Size:	129.1 KB
ID:	363073
Gently remove the A-pillar (if you force it, the connector at the dashboard will break).
Click image for larger version

Name:	DSCN1871.jpg
Views:	550
Size:	164.0 KB
ID:	363074
Disconnect the wire coming from the old edge protector. Remove the edge protector entirely, and discard. Find the rubber flap on your new edge protector and connect it to the black plug near the fender.
Click image for larger version

Name:	DSCN1873.jpg
Views:	533
Size:	112.7 KB
ID:	363076
Connect the wire to the plug on the A-pillar. Find the right angle on the edge protector and press it into place in the upper-rear section of your door. You need to cram it in as far as you can get it (a rubber mallet is helpful here).
Click image for larger version

Name:	DSCN1874.jpg
Views:	397
Size:	129.7 KB
ID:	363077
Work your way straight down, pressing the protector into place. If the notch in the protector lines up with the trim from the rear window, you know you're on the right track.
Click image for larger version

Name:	DSCN1877.jpg
Views:	374
Size:	102.7 KB
ID:	363080
Keep working around the door frame pushing the protector into place. The protector has a handy feature to tell you that you've screwed up and you need to start over.
Click image for larger version

Name:	DSCN1876.jpg
Views:	399
Size:	144.9 KB
ID:	363079
I used a rubber mallet to knock it into place, and that seemed to work well. Once you've got it in, push the rubber lining underneath the trim along the upper portion of the doorframe.
Click image for larger version

Name:	DSCN1875.jpg
Views:	401
Size:	118.1 KB
ID:	363078
Reattach your A-pillar cover. Getting the Torx bolts back in was even worse than getting them out -- I finally shot some WD-40 into the holes, and that did the trick. Put the HPS strip back in place, and presto!
Click image for larger version

Name:	DSCN1878.jpg
Views:	404
Size:	152.1 KB
ID:	363081
Reconnect your battery (positive terminal first), and job's done.
